CP-602E-I Serie | 2 Ports CAN Interface PCI Express Board

Features and Benefits

  • CAN 2.0A and CAN 2.0B supported
  • Two independent CAN communication ports
  • CAN transfer rate up to 1 Mbps
  • 2 kV electrical isolation
  • LED for transmit/receive status on each port
  • Optional 120 ohm terminal resistor for CAN bus network
  • DLL library and examples included
  • Windows driver provided

Overview

Moxa’s new CP-602E-I CAN (Controller Area Network) interface board supports the PCI Express interface. As a stand-alone CAN controller, the CP-602E-I is a cost-effective solution that provides two active CAN controllers with a DB9 connector on the same board. The CP-602E-I CAN interface board uses the NXP SJA1000 and transceiver PCA82C251, which provide the bus arbitration and error detection. The -40 to 85°C wide operating temperature (CP-602E-I-T only) and 2 kV isolation make the boards suitable for use in harsh industrial environments.

Gesamten Text anzeigen

Downloads

Artikel Downloads / Links Preis Anzahl
01030361 : CP-602E-I w/o Cable CHF 488.00
01030362 : CP-602E-I-T w/o Cable CHF 567.00
